AXIS M1065-LW

Small, full-featured wireless indoor cube camera for day & night surveillance. 2.8mm fixed lens with 110° HFOV. Automatic IR cut filter. IR illumination up to 10 meters (33 feet) . Multiple, individually configurable H.264 and Motion JPEG streams; max HDTV 1080p at 30 fps with WDR.

 Axis’ Zipstream technology for reduced bandwidth and storage needs. Memory card slot for optional local video storage. Built-in microphone and mini-speaker, integrated PIR motion sensor. Connects over wireless LAN (IEEE 802.11a/b/g/n) or wired Ethernet. Supports Wi-Fi Protected Setup™ PBC compatible. Includes wall, corner bracket and table top bracket for easy mounting. Power supply included.

Technical specifications

Camera

Image sensor CMOS

Image sensor size 1/3

Lightfinder –

Wide dynamic range WDR

Min illumination/ light sensitivity (Color) 0.25 lux

Min illumination/ light sensitivity (B/W) 0.05 lux

Video
Max video resolution 1920x1080

Max frames per second 25/30

Electronic image stabilization –

Lens

Focal length 2.8 mm

Horizontal field of view 110 °

Vertical field of view 61 °

Lens mount M12

Replaceable lens –

Compression

Zipstream Yes

H.264 Baseline, High, Main

H.265 –

Motion JPEG Yes

Audio

Audio Support Yes

Network

PoE Class –

Wireless Yes

Security

Signed firmware Yes

Secure boot –

General

Remote focus –

Remote zoom –

Built-in IR Yes

Local storage (memory card slot) Yes

Operating temperature 0 to 40 °C

Outdoor Ready –

Vandal rating –

IP rating –

Designed for repaint –

Sustainability PVC free

Power

Power (max) 5.0 W

Power (average) 2.7 W

DC input voltage 4.75-5.25 V
