EXCAM XF M3016

Explosion-protected, PoE powered, 3 MP fixed network camera, ATEX/IECEx/EAC-Ex/IA/PESO certified for hazardous locations. Ex II 2 G Ex d IIC T6 Gb, Ex II 2 D Ex t IIIC T80°C Db IP68, -5ºC <= Ta <= +50ºC (intermittent). Model key:T08-VA1.2.K1.BOR-N.N-005.N-P-090. Stainless steel 316L housing. 2.8mm F2.0 lens. Zipstream, WDR. AXIS Surveillance SD Card 128GB, 5m network cable preinstalled. Built to order, 6 weeks lead time.

Technical specifications

Camera

Image sensor CMOS

Image sensor size 1/3

Lightfinder –

Wide dynamic range WDR

Min illumination/ light sensitivity (Color) 0.4 lux

Min illumination/ light sensitivity (B/W) –

Video

Max video resolution 2304x1296

Max frames per second 25/30

Electronic image stabilization –

Lens

Focal length 2.8 mm

Optical zoom –

Horizontal field of view 92 °

Vertical field of view 52 °

Compression

Zipstream Yes

H.264 High, Main

H.265 Yes

Motion JPEG Yes

Network

PoE Class 1

Security

Signed firmware Yes

Secure boot –

TPM –

General

Remote focus –

Remote zoom –

Local storage (memory card slot) Yes

Outdoor Ready Yes

IP rating IP68

Power

Power (max) –

Power (average) –

DC input voltage –

AC input voltage –
