| System |
| Main Processor | Industrial embedded micro-processor |
| Operating System | Embedded Linux |
| Operation Interface | Web/local GUI |
| Perimeter Protection |
| Performance | 24 channels |
| AI Search | Search pictures by channel, time, event type |
| Face Detection By Camera |
| Performance | 24 channels |
| Face Attributes | 6 attributes: Gender, age, glasses, expression, mouth mask, and beard |
| AI Search | Search pictures by channel, time and face attributes |
| SMD Plus By Camera |
| Performance | 32 channels |
| AI Search | Search by target classification (Human, Vehicle) |
| Video Metadata By Camera |
| Performance | 12 channels |
| Human Body | Top, top color, bottom, bottom color, hat, bag, gender, age, umbrella |
| Vehicle | Plate No., type, color, vehicle type, logo, plate color, ornament, calling, seatbelt, region |
| Non-motor Vehicle | Type, color, number of passengers, helmet |
| AI Search | Support search target video by metadata |
| ANPR By Camera |
| Performance | 8 channels |
| Stereo Analysis by Camera |
| Performance | 32 channels |
| AI Search | Search by target classification (Fall Detection, People Approach Detection, People No. Exception Detection, People Staying Detection, Violence Detection) |
| Video |
| Access Channel | 32 |
| Network Bandwidth | 384 Mbps for access, 384 Mbps for storage and 384 Mbps for forwarding |
| Resolution | 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/
1080p/960p/720p/D1/CIF/QCIF |
| Decoding Capability | 16-ch@1080p (30 fps) |
| Video Output | VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
HDMI1/HDMI2: 3840 × 2160@30 fps, 3840 × 2160@25fps, 1920 × 1080, 1280 × 1024, 1280 × 720
1 channel VGA output, 2 channels HDMI output, VGA and HDMI 1 homologous output, double HDMI heterogeneous output. Support 4K display for both HDMI1 and HDMI2 |
Multi-screen Display | 1st Screen: 1/4/8/9/16/25/36 |
| 2nd Screen: 1/4/8/9/16 |
| Third Party Camera Access | Panasonic, Sony, Samsung, Axis, Pelco, Arecont, Onvif, Canon and more |
| Compression |
| Video | Smart H.265+/H.265/Smart H.264+/H.264/MPEG4/MJPEG |
| Audio | MP2/G726/G729/G722/G723/G711A/G711U/PCM |
| Network |
| Network Protocol | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.), P2P, iSCSI |
| Mobile Phone Access | iOS, Android |
| Interoperability | ONVIF (profile T/S/G), CGI, SDK |
| Browser | Chrome, IE9 or later, Firefox |
| Record Playback |
| Multi-channel Playback | 1/4/9/16 |
| Record Mode | Manual, Schedule (General, MD (Motion Detection), Alarm, MD & Alarm, Intelligent, POS) |
| Storage Method | Local HDD and network |
| Backup | Hard drive, USB device, eSATA device |
| Playback Function | 1. Play, pause, stop, fast forward, fast backward, rewind, play by frame
2. Full screen, backup (cut/file), partially enlarge, audio on/off |
| Storage |
| Disk Group | Support |
| Raid Support | RAID 0/1/5/6/10 |
| Alarm |
| General Alarm | Motion detection, privacy masking, video loss, local alarm, PIR alarm, IPC alarm |
| Anomaly Alarm | Camera offline, storage error, full storage, IP conflict, MAC conflict, login lock, network security anomaly |
| Intelligent Alarm | Perimeter protection, face detection, face recognition, SMD, video metadata
(human, motor-vehicle, non-motor vehicle), ANPR, people counting, stereo analysis, crowd distribution, heatmap, video quality diagnosis |
| Alarm Linkage | Record, snapshot, IPC external alarm output, buzzer, log, preset, email |
| External Port |
| Audio Input | 1 channel, RCA connector |
| Audio Output | 1 channel, RCA connector |
| HDD | 8 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature. |
| Alarm Input | 16 channels |
| Alarm Output | 8 channels |
| eSATA | 1 eSATA |
| RS-232 | 1 channel, used to debug and pass through serial data |
| RS-485 | 1 channel, used to control PTZ, and it supports multiple protocols |
| USB | 2 front USB 2.0 ports, 2 rear USB 3.0 ports |
| Network | 2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet ports |
| General Parameter |
| Power Supply | Single, AC100V–240V, 50–60 Hz |
| Power Consumption | < 20 W (Without HDD) |
| Net Weight | 9 kg (19.8 lb) (Without HDD) |
| Gross Weight | 10.5 kg (23.1 lb) (Without HDD) |
| Product Dimensions | 440 mm × 452.6 mm × 94.9 mm (W × L × H)
17.32 inch × 17.82 inch × 3.73 inch (W × L × H) |
| Package Dimensions | 571 mm × 571 mm × 225 mm (W × L × H)
22.48 inch × 22.48 inch × 8.86 inch (W × L × H) |
| Operating Conditions | –10°C to +55°C (+14°F to +131°F), +35°C (+95°F) when raid enabled |
| Storage Conditions | 0°C to +40°C (+32°F to +104°F) |
| Operating Humidity | 10%–93% (RH) |
| Storage Humidity | 30%–85% (RH) |
| Operating Altitude | 3000 m (9843 ft) |
| Certifications | CE: EN55022, EN55024, EN50130-4, EN60950-1
FCC: Part 15 Subpart B, ANSI C63.4-2014
UL: UL 60950-1 and CAN/CSA C22.2 No.60950-1 |
