WISENET SNP-L6233H

SNP-L6233H

2MP Full HD 23x Network PTZ Dome

The SNP-L6233H Wisenet Lite PTZ dome camera from Hanwha Techwin provides 23x zoom at 2 megapixel HD resolution. This Outdoor PTZ Dome camera has the ability to zoom in with perfect clarity at an incredible speed allowing you to track your evidence while capturing smooth video.

• SNP-L6233HN/HP SNP-L6233N/P
• VIDEO
• Imaging Device 1/2.8? 2.38M CMOS
• Total/ Eective Pixels 1,952(H) x 1,116(V), 2.18M pixels/ 1,944(H) x 1,104(V), 2.14M pixels
• Scanning System Progressive
• Min. Illumination
• Color : 0.3Lux (1/30sec, F1.6, 50IRE, AGC high) , 0.005Lux (2sec, F1.6, 50IRE, AGC high)
• B/W : 0.03Lux (1/30sec, F1.6, 50IRE, AGC high), 0.0005Lux (2sec, F1.6, 50IRE, AGC high)
• Color : 0.15Lux (1/30sec, F1.6, 30IRE), 0.0025Lux (2sec, F1.6, 30IRE)
• B/W : 0.015Lux (1/30sec, F1.6, 30IRE), 0.00025Lux (2sec, F1.6, 30IRE)
• S / N Ratio 50dB
• Video Output CVBS : 1.0 Vpp / 75O composite, 720 x 480(N), 720 x 576(P), for installation
• LENS
• Focal Length (Zoom Ratio) 4.44 ~ 102.1mm (Optical 23x)
• Max. Aperture Ratio F1.6(Wide) / F3.63(Tele)
• Angular Field ofView H : 62.8°(Wide) ~ 3.14°(Tele) / V : 36.8°(Wide) ~ 1.76°(Tele)
• Min. Object Distance Wide : 1.5m (4.92ft), Tele : 1.9m (6.23ft) Wide : 1.5m (4.92ft), Tele : 2m (6.56ft)
• Focus Control Auto / Manual/ One push
• Lens/ Mount Type DC auto iris/ Board-in type
• PAN / TILT / ROTATE
• Pan / Tilt Range 360° Endless/ 210° (-15° ~195°)
• Pan / Tilt Speed Preset : 500°/sec, Manual : 0.024°/sec ~ 120°/sec
• Sequence Preset (255ea), Swing, Group (6ea), Trace, Tour (1ea), Auto run, Schedule
• Preset Accuracy ±0.2°
• Azimuth Yes(E / W / S / N / NE / NW / SE / SW)
• OPERATIONAL
• Camera Title O / On (Displayed up to 45 characters)
• Day & Night Auto (ICR)/ Color / B/W
• Backlight Compensation O / BLC
• Wide Dynamic Range 100dB
• Contrast Enhancement SSDR (O / On)
• Digital Noise Reduction SSNRIII (2D+3D noise lter) (O / On)
• Digital Image Stabilization O / On
• Defog O / Auto / Manual
• Motion Detection O / On (4ea rectangle zone)
• Privacy Masking O / On (32 zones of rectangle zone) with zoom threshold mosaic option
• Gain Control O / Low / Middle / High
• White Balance ATW / AWC / Manual / Indoor / Outdoor/ Mercury
• Electronic Shutter Speed Minimum / Maximum / Anti icker (2 ~ 1/12,000sec)
• Digital Zoom 12x
• Flip / Mirror O / On
• IntelligentVideo Analytics Tampering, Virtual line, Enter/ Exit, (Dis)Appear, Audio detection, Face detection
• Alarm I/O Input 4ea / Output 2ea (Relay)
• Remote Control Interface RS-485
• RS-485 Protocol Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, Bosch, GE
• AlarmTriggers Motion detection, Tampering, Audio detection, Face detection,
• Video analytics, Alarm input, Network disconnection
• Alarm Events File upload via FTP and E-mail, Notication via E-mail, TCP and HTTP, Localstorage (SD/SDHC/
• SDXC) or NAS recording at network disconnected & event (Alarm triggers), External output
• NETWORK
• Ethernet RJ-45 (10/100BASE-T)
• Video Compression Format H.264 (MPEG-4 part 10 / AVC), MJPEG
• Resolution 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768,
• 800 x 600, 800 x 450, 720 x 576, 640 x 480, 640 x 360, 320 x 240, 320 x 180
• Max. Framerate
• H.264 : Max. 30fps at all resolutions
• MJPEG : 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 : Max. 15fps
• 800 x 600, 800 x 450, 720 x 576, 640 x 480, 640 x 360, 320 x 240, 320 x 180 : Max. 30fps
• Smart Codec Manual mode (Area-based : 5ea), Face detection mode
• VideoQuality Adjustment H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
• Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
• Streaming Capability Multiple streaming (Up to 10 proles)
• Audio In Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm
• Audio Out Line out (3.5mm mono jack), Max output level : 1 Vrms
• Audio Compression Format G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz,
• G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
• Audio Communication Bi-directional audio
• IP IPv4, IPv6
• Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
• Security
• HTTPS(SSL) login authentication, Digest login authentication
• IP address ltering, User accesslog, 802.1x authentication
• Streaming Method Unicast/ Multicast
• Max. User Access 10 users at unicast mode
• Edge Storage
• SD/SDHC/SDXC slot forsupporting memory card
• Motion imagesrecorded in the SD/SDHC/SDXC memory card can be downloaded
• NAS (Network Attached Storage)
• Application Programming Interface ONVIF prole S, SUNAPI (HTTP API), SVNP 1.2
• Webpage Language
• English, French, German, Spanish, Italian, Chinese, Russian, Japanese,
• Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch,
• Croatian, Hungarian, Greek, Finnish, Norwegian
• WebViewer
• Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7
• Supported Browser : Microsoft Internet Explorer (Ver. 8 ~ 11), Mozilla Firefox (Ver. 9 ~ 19),
• Google Chrome (Ver. 15 ~ 25), Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7)
• * Mac OS X only
• Central Management Software SmartViewer, SSM
• ENVIRONMENTAL
• OperatingTemperature / Humidity
• 24V AC : -50°C ~ +55°C (-58°F ~ +131°F) /
• Lessthan ~ 90% RH
• PoE+ : -30°C ~ +55°C (-22°F ~ +131°F)/
• Lessthan 90% RH
• -10°C ~ +55°C (+14°F ~ +131°F)/
• Lessthan 90% RH
• Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Lessthan 90% RH
• Ingress Protection /Vandal Resistance IP66 / IK10 N/A /IK10 (With SHP-3701H)
• ELECTRICAL
• InputVoltage / Current 24V AC ±10%, PoE+ (IEEE802.3at, Class4)
• Power Consumption 24V AC : Max. 65W (24V AC heater on & PoE heater on)
• PoE+ : Max. 25W (24V AC heater o / PoE heater on) Max. 20W
