Cisco Catalyst C9500-48Y4C-A
The Cisco C9500-48Y4C-E switch delivers high-performance networking with 1.6 Tbps capacity, 82,000 MAC addresses, and 212,000 IPv4 and IPv6 routes. It supports 16,000 QoS ACLs and 27,000 security ACLs, with 16 GB DRAM, 16 GB flash storage, and 4,000 VLAN IDs and SVIs. Jumbo frames up to 9,216 bytes are supported. It can be powered by C9K-PWR-650WAC-R or C9K-PWR-930WDC-R and occupies 1 RU of space. Operating temperature ranges from 32° to 104°F (0° to 40°C), with an input voltage of 90-264 VAC. It's reliable with an MTBF of 316,960 hours.
Performance specifications | |
Switching capacity | Up to 1.6 Tbps |
Forwarding rate | Up to 1 Bpps |
Total number of MAC addresses | Up to 82,000 |
Total number of IPv4 routes (Address Resolution Protocol [ARP] plus learned routes) | Up to 212,000 indirect + direct Up to 90,000 host/ARP |
Total number of IPv6 routes | Up to 212,000 indirect + direct Up to 90,000 host |
QoS ACL scale | Up to 16000 |
Security ACL scale | Up to 27000 |
FNF entries | Up to 98,000 |
DRAM | 16 GB |
Flash | 16 GB |
VLAN IDs | 4000 |
Total Switched Virtual Interfaces (SVIs) | 4000 |
Jumbo frame | 9216 bytes |
Power supply specifications | |
Power Supply Selection | C9K-PWR-650WAC-R or C9K-PWR-930WDC-R |
Dimensions, physical specifications, weight, and MTBF | |
Dimensions (H x W x D) | 1.73 x 17.5 x 18.0 in |
Rack units (RU) | 1 RU |
Chassis with 2 power supplies and built-In fan | 21.96 lb (9.96 kg) |
Input voltage | 90 to 264 VAC |
Operating temperature | 32° to 104°F (0° to 40°C) |
Storage temperature | -4° to 149°F (-20° to 65°C) |
Relative humidity operating and nonoperating noncondensing | Ambient (noncondensing) operating: 5% to 90% Ambient (noncondensing) nonoperating and storage: 5% to 95% |
Altitude | Operation up to 13,000 feet at 40°C |
MTBF (hours) | 316,960 |
