| MS350-24P-HW Specification |
| Interfaces | • 24 x 10/100/1000BASE-T Ethernet RJ45
with with auto negotiation and auto-MDIX3
• 4 x SFP+ 10G uplink
• 2 x stacking ports |
| Switching capacity | 128 Gbps |
| Stacking Bandwidth | 160G (dual interface) |
| Forwarding rate | 95.24 mpps |
| Available PoE+ Power | 370 W |
| Idle / Full Load Power | 57 / 466 W |
| Power Supply Configuration | Hot-swappable |
Optional Redundant Power
Supply | 2 x 640W PSU |
| What’s included | 1 x Power Supply (MA-PWR-640WAC),
Mounting screw kit, 1 x Stacking Cable
(0.5m), 2 x Pre-Installed Fans |
| Dimensions | 1.74” x 19.08” x 20.4” (4.44cm x 48.46cm
x 51.81cm) |
| Weight | 13.14 lb (5.96 kg) |
| Management | • Managed via the Web with the Meraki
cloud management platform
• Integrated with Meraki Wireless and
complete portfolio of IT products
and solutions
• Zero-touch remote provisioning
(no staging needed)
• Detailed historical per-port and
per-client usage statistics
• DHCP, client, and hostname
fingerprinting
• SNMPd and SYSLOG support for
integration with other network
management solutions
• Automatic firmware upgrades with
scheduling control |
| Layer 3 | • Static routing, OSFPv2
• Multicast routing
• Warm Spare (VRRP)
• DHCP Relay, DHCP Server |
| Remote Diagnostics | • Email, SMS and Mobile push notification
alerts
• Cable testing and link failure detection
with alerting
• Live remote packet capture
• Dynamic and interactive network
discovery and topology
• Combined event and configuration
change logs with instant search |
| Power | • Power input: 100 - 240 VAC, 47-63 Hz
• Power consumption: 56 - 888W |
| Stacking | • Physical stacking of up to 8 switches with
160 Gbps stack bandwidth on all models
• Virtual stacking supports thousands of
switch ports in a single logical stack for
unified management, monitoring, and
configuration |
| Mounting | • 1U Rack-mountable with included rack
mount hardware
• 2-post front mounting options available |
| Ethernet Switching Capabilities | • 802.1p Quality of Service, 8 queues
(w/ 6 configurable for DSCP-to-CoS
mapping)
• 802.1Q VLAN and trunking support for
up to 4,094 VLANs
• 802.1w, 802.1D Rapid Spanning
Tree Protocol (RSTP, STP)
• Broadcast storm control
• 802.1ab Link Layer Discovery Protocol
(LLDP) and Cisco Discovery Protocol
(CDP)
• 802.3ad Link aggregation with up to 8
ports per aggregate, Multichassis
aggregates supported on stacked switches
• Port mirroring
• IGMP snooping for multicast filtering
• MAC forwarding entries: 32K |
| Environment | • Operating temperature: -5°C to 50°C
• Humidity: 5 to 95% non-condensing
• Variable speed fans |
| Regulatory | • CSA-US (US, Canada)
• FCC (USA)
• IC (Canada)
• CE (Europe)
• RCM (Australia/New Zealand)
• RoHS |
| Security | • Integrated two-factor authentication for
Dashboard management
• Role-based access control (RBAC) with
granular device and configuration control
• Corporate wide password policy
enforcement
• IEEE 802.1X RADIUS and MAB,
hybrid authentication and RADIUS
server testing
• Multi-Domain/Multi-Host/Multi
Authentication
• Port security: Sticky MAC, MAC
whitelisting
• DHCP snooping, detection and
blocking, Dynamic ARP Inspection
• STP Enhancements: BPDU guard,
Root guard, Loop guard
• IPv4 and IPv6 ACLs |
| MTBF Ratings | 568,000 |
