DAHUA DH-PFS3008-8ET-L

5 Port PoE Switch

System Overview

8 × 10/100 Mbps adaptive ports, highly integrated design, compact,

portable, easy to operate, suitable for small and medium office and

home networks.

Application

The product is applicable to small and medium office and home

networks.

Technical Specification

Performance

Layer Layer 2

Managed No

Hardware

Standard Power Supply Yes

PoE No

Ethernet Port 8

Ethernet Port Rate 100 Mbps

Power Supply 5V/500mA DC

Operating Temperature -10°C to 55°C (14°F to 131°F)

Operating Humidity 10%–90%

Storage Temperature -40°C to 70°C (-40°F to 158°F)

Storage Humidity 10%–90%

Power Consumption Idling: 0.69W

Full load: 1.5W

Performance

Switching Capacity 1.6 Gbps

Packet Forwarding Rate 1.19 Mpps

Packet Buffer Memory 448 Kbits

MAC Table Size 1K

Standards Compliance IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE802.3x
