Time to upscale your display
Samsung’s QHR series displays feature best-in-class UHD resolution with unmatched 700 nit brightness, ideal for locations requiring high visibility. The displays also feature intelligent UHD upscaling for stunning picture quality, all in a slim design.
Incredible 4K picture quality
Empower your customers to experience pure visual innovation with lifelike images in sharper picture quality than ever before.
SPECIFICATIONS
Display
Diagonal Size 1m 89cm (75?)
Panel Type New Edge, 60Hz
Resolution 3,840 x 2,160
Pixel Pitch (HxV) 0.42975(H) x 0.42975(V) (mm)
Brightness (Typical) 700
Contrast Ratio 4,000:1
Viewing Angle (H/V) 178/178
Response Time 8ms
Color Gamut 92% (DCI-P3, CIE 1976)
Glass Haze 0.44 %
H-Scanning Frequency 30 ~ 135kHZ
Maximum Pixel Frequency 594MHz
V-Scanning Frequency 48 ~ 75HZ
Dynamic Contrast Ratio Mega
Connectivity
HDMI In 2
DP In Yes
DVI In 1
USB 2
IR In Yes
Audio In Yes
Audio Out Stereo Mini Jack
Video Out Yes
RS232 In Yes
RS232 Out Yes
RJ45 In Yes
WiFi Yes
Bluetooth Yes
Power
Power Supply AC100-240V 50/60Hz
Power Consumption (On Mode) 314
Power Consumption (Sleep Mode) 0.5 W
Dimension
Set Dimension (WxHxD) 1681.1 x 960.1 x 49.7 mm
Package Dimension (WxHxD) 1871 x 1127 x 223 mm
Weight
Set Weight 40.3 kg
Package Weight 51 kg
Operation Conditions
Temperature 0?~ 40?
Humidity 10 ~ 80%, non-condensing
Mechanical Specification
VESA Mount 400 x 400 mm
Bezel Width 11.5(U/L/R), 12.5(D)
Frame Material Non-Glossy
Optional Feature
Mount WMN6575SE,WMN4277SE
Internal Player (MagicInfo)
MagicInfo Daisychain Videowall Support Yes
