UBIQUITI NANOSTATION M5

Ubuquiti Nanostation m5

Indoor/Outdoor airMAX® CPE

Featuring a panel antenna and dual-polarity performance, the NanoStation®M is ideal for Point-to-MultiPoint (PtMP) applications requiring high-performance CPE devices with a sleek form factor.

Models: locoM2, locoM5, locoM9, NSM2, NSM3, NSM365, NSM5

Compact CPE Design

The NanoStation®M features the CPE design that expanded the global Wireless ISP industry.

Plug and Play Installation

The NanoStation®M requires no tools for assembly; only a single wrench is required for pole-mounting.

Versatile Application Use

The NanoStation®M can be deployed for Point-to-Point (PtP) bridging, wireless connectivity to a video surveillance system, or use as an airMAX® CPE.

Dual Ethernet Connectivity

With software-enabled PoE output, the secondary Ethernet port can power an external device, such as a PoE security camera, for seamless IP video integration

Detailed Description:

Powerful airOS® Features

Ubiquiti’s versatile airOS® firmware technology enables high-performance, outdoor multi-point networking. airOS provides features such as wireless settings, bridge or routing configuration and system management services.

Advanced Software Technology

Ubiquiti’s airMAX® technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.

Window/Wall Mounting Kit

Use the NanoStation® Mount to quickly mount the NanoStationM on a window or wall. 180° vertical or horizontal adjustment allows for custom positioning.

Wall/Pole Mounting Kit

The Universal Arm Bracket is designed for convenient wall or pole mounting of the NanoStation®M. 90° tilt adjustment allows for easy positioning.

Model Comparison

locoM9

locoM9

NSM2

NSM2

locoM2

locoM2

NSM3

NSM3

NSM365

NSM365

Frequency 900 MHz 2.4 GHz 2.4 GHz 3 GHz 3.65 GHz

Throughput 150+ Mbps 150+ Mbps 150+ Mbps 150+ Mbps 150+ Mbps

Range 10+ km 13+ km 5+ km 15+ km 15+ km

NSM5

NSM5

locoM5

locoM5

Frequency 5 GHz 5 GHz

Throughput 150+ Mbps 150+ Mbps

Range 15+ km 10+ km
